Adhesive Label / Sticker Label / Paper Label Slitting Rewinding Machine

Main Parameters:
ModelTFQ-1300 Slitter
Max Feeding Width(mm)1300
Main Engineer Power(kw)6
Speed(T/M)80
Size(L*W*H)(m)3.2*2.3*1.3
Weight(kg)2900
Unwinding diameter(mm)800
Rewinding diameter(mm)450
precision(mm)±0.10
Total Power8.5KW
Voltage3P 380V 50HZ

Functional characteristics:
This machine is slitting equipment of high precision and high sensitivity, with inflatable bearing is used for feeding and receiving materials. Imported magnetic powder clutch is adopted to control the tension. Imported gas sensitive device is adopted to detect the rectification of rolling, with fully automatic hydraulic rectification control. Automatic detection, rectification and metering can be realized. It is characterized by accurate slitting, fast slitting speed, ease of operation and maintenance, etc. There are two selection for main engine, single electric motor, double electric motors.

Purpose:
It is applicable for the slitting tooling of industrial adhesive tape, cellphone tape, protective film, copper foil, aluminum foil, OPP, PE, PVC, sheet, cloth, etc. This machine is widely used in the industries such as printing, packing, electronics, leather, clothes making, plastic, etc.


Adhesive Label / Sticker Label / Paper Label Slitting Rewinding Machine

Adhesive Label / Sticker Label / Paper Label Slitting Rewinding Machine

Adhesive Label / Sticker Label / Paper Label Slitting Rewinding Machine

Adhesive Label / Sticker Label / Paper Label Slitting Rewinding Machine
Adhesive Label / Sticker Label / Paper Label Slitting Rewinding Machine
MOQ1 Set
Packing Detailpacking(inner): Stretch film
Packing(outside):Wooden frame
Delivery Time20-40 days after get your deposit and confirmed all the Details
Delivery PortShanghai
Terms Of PaymentL/C T/T Western Union
GuaranteeThe whole machine is guaranteed for one year.
